A9K-MPA-20X1GE is Cisco ASR 9000 Series Router 20-port 1GE Modular Port Adapter. Cisco ASR 9000 Series modular line cards provide customers with a flexible solution supporting multiple combinations of Ethernet ports, all in a single slot of the Cisco ASR 9000 Series Aggregation Services Routers.
| Description | Specification |
| Chassis compatibility | Compatible with the Cisco ASR 9922, 9010, 9006 and 9001 systems |
| Port density | Up to 2 modular port adapters are supported per line card.. |
| Ethernet | ● IEEE 802.3 compliant
● 10 Gigabit Ethernet PHY monitoring ● IEEE 802.x flow control ● Full-duplex operation ● Per-port byte and packet counters for policy drops; oversubscription drops; cyclic redundancy check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets |
| Card density | Maximum number of line cards per system: Cisco ASR 9922 = 20, Cisco ASR 9010 = 8, and Cisco ASR 9006 = 4 |
| Options | Each line card is available as either a Service Edge Optimized (enhanced QoS) or Packet Transport
Optimized (basic QoS) line card. |
| Reliability and availability | Line card online insertion and removal (OIR) support without system impact |
| Network Equipment Building Standards (NEBS) | Cisco ASR 9000 Series Routers are designed to meet:
● SR-3580: NEBS Criteria Levels (Level 3) ● GR-1089-CORE: NEBS EMC and Safety ● GR-63-CORE: NEBS Physical Protection |
| Operating temperature (nominal) | 41 to 104ºF (5 to 40ºC) |
| Operating temperature (short-term)[1] |
23 to 131ºF (–5 to 55ºC) |
| Operating humidity (nominal) relative humidity | 10 to 85% |
| Storage temperature | –40 to 158ºF (–40 to 70ºC) |
| Storage relative humidity | 5 to 95%
Note: Not to exceed 0.024 kg of water per kg of dry air |
| Operating altitude | –60 to 4000m (up to 2000m conforms to IEC, EN, UL, and CSA 60950 requirements) |
| ETSI standards | Cisco ASR 9000 Series Routers are designed to meet:
● EN300 386: Telecommunications Network Equipment (EMC) ● ETSI 300 019 Storage Class 1.1 ● ETSI 300 019 Transportation Class 2.3 ● ETSI 300 019 Stationary Use Class 3.1 ● EN55022: Information Technology Equipment (Emissions) ● EN55024: Information Technology Equipment (Immunity) ● EN50082-1/EN-61000-6-1: Generic Immunity Standard |
| EMC standards | Cisco ASR 9000 Series Routers are designed to meet:
● FCC Class A ● ICES 003 Class A ● AS/NZS 3548 Class A ● CISPR 22 (EN55022) Class A ● VCCI Class A ● BSMI Class A ● IEC/EN 61000-3-2: Power Line Harmonics ● IEC/EN 61000-3-3: Voltage Fluctuations and Flicker |
| Immunity | Cisco ASR 9000 Series Routers are designed to meet:
● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ● IEC/EN-61000-4-3: Radiated Immunity (10V/m) ● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ● IEC/EN-61000-4-5: Signal Ports (1kV) ● IEC/EN-61000-4-5: Surge DC Port (1kV) ● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations |
| Safety | Cisco ASR 9000 Series Routers are designed to meet:
● UL/CSA/IEC/EN 60950-1 ● IEC/EN 60825 Laser Safety ● ACA TS001 ● AS/NZS 60950 ● FDA: Code of Federal Regulations Laser Safety |
